CenterPoint Energy Waterville Gas Storage Project
by John Heer, PE, Allen Boerboom, and Tyler Froman, CenterPoint Energy
Presentation Overview
CenterPoint Energy operates underground natural gas storage and production facilities near Waterville in southern Minnesota. The facilities are used to store natural gas during the summer and withdraw gas during periods of peak needs in the winter. This is an aquifer storage site. The gas is stored about 800 to 900 feet underground below an anticline formation of non-porous shale. Below the non-porous rock is a natural sandstone aquifer called the Mt Simon. The gas is held in place by the natural pressure of the water in the aquifer.
The storage formation holds seven billion cubic feet of natural gas. Two billion cubic feet of this working gas; this is the gas that can be cycled each year for storage and production.
The production section of the facility has a maximum capacity to output 50,000 MCF/Day, (approximately 50,000,000,000 BTUs of energy per day). The gas is withdrawn from the storage field, compressed, dried, and delivered to the Interstate Pipeline system near Medford, MN.
The storage facility development began in 1966 with the first gas injected in 1968. It has been in continuous service since then.
The Minnesota Department of Natural Resources regulates the storage of gas underground.
|
Total Gas Storage Capacity (DNR Permitted) |
7,000,000 MCF
|
|
Working Gas |
2,000,000 MCF |
|
Production Capacity |
50,000 MCF/Day |
|
Compression |
~2,500 HP |
|
Injection/Withdrawal Wells |
29 |
|
Surface Area Above Stored Gas |
4,400 acres |
|
Field Aquifer Discovery Pressure |
293 Psig |
Figure 1: Waterville Gas Storage
Biography
John Heer, P.E., Director of Gas Storage & System Planning.
Allen Boerboom, Waterville Gas Storage Supervisor.
Tyler Froman, Senior Reservoir Engineer.
CenterPoint Energy, Inc., headquartered in Houston, Texas, is a domestic energy delivery company that includes electric transmission & distribution, natural gas distribution and energy services operations. With more than 9,600 employees, CenterPoint Energy and its predecessor companies have been in business for more than 140 years.
